TF1100-MI   Transit-Time Multi-channel Insertion Ultrasonic Flowmeter

Features:

       1. Works on the multi-channel transit-time principle. The accuracy is 0.5%.

       2. Wide bi-directional Flow range of 0.01 m/s to 12 m/s. Repeatability is less than 0.15%.

       3. Low starting flow, super wide turndown ratio Q3:Q1 as 400:1.

       4. 3.6V 76Ah battery power supply，with lifetime over 10 years (measuring cycle: 500ms).

       5. With storage function. Can storage both forward flow and back flow data 10 years (day, month, year ).

       6. Hot-tapped installation, no pipe line flow interrupted.

       7. Standard output is RS485 modbus, Pulse, NB-IoT, 4G, GPRS, GSM can be optional.

       8. Two channels and four channels can be optional.

Specifications

Applications：

General

● Service and maintenance

● Replacement of defective devices

● Support of commissioning process and installation

● Performance and efficiency measurement

- Evaluation and assessments

- Capacity measurement of pumps

- Monitoring of regulating valves

● Energy efficiency audits

Water and waste water industry - hot water, cooling water, potable water, sea water etc.)

Petrochemical industry

Chemical industry -chlorine, alcohol, acids, .thermal oils.etc

Refrigeration and air conditioning systems

Food , beverage and pharmaceutical industry

Power supply- nuclear power plants, thermal & hydropower plants), heat energy boiler feed water.etc

Metallurgy and mining applications

Mechanical engineering and plant engineering-pipeline leak detection, inspection, tracking and collection.
